One vs Two Kanban Loop

Illustration of the two options for a two process system: You can make one big Kanban or CONWIP loop, or two smaller loops with a FIFO in between. Customer is also shown. Image in Black & white. This image by me is licensed under the Creative Commons Attribution-Share Alike 4.0 International license. Please credit the image as shown below. For digital documents and web pages please do include the links as shown below. Thank you.

By Christoph Roser at AllAboutLean.com under the free CC-BY-SA 4.0 license.

File Name: one-vs-two-loop.png
File type: png
File size: 6.78 KB
Dimensions: 743 x 424
Date: April 4, 2016
SEO Title: One vs Two Kanban Loop
SEO Description: Illustration of the two options for a two process system: You can make one big Kanban or CONWIP loop, or two smaller loops with a FIFO in between. Customer is also shown. Image in Black & white.
SEO Keywords: Supermarket , FIFO
Post or page attached: Supermarket vs. FiFo – What Requires Less Inventory?,
